The Uniphos FumiGuard is an advanced continuous gas detection system for detecting Phosphine (PH3). It has been specially designed for applications like fence line or peripheral monitoring of a fumigated area.
It comprises of a master control unit and up to 8 gas detection heads. The modular design of the system enables the user to easily connect multiple detection heads in a loop (daisy chain), saving cable cost in the process. With in-built GSM connectivity, the gas readings are uploaded to the cloud, where they can be viewed from anywhere in the world on a laptop or mobile device and alarm functions can easily be configured, allowing 24/7 perimeter monitoring and ensuring compliance to local regulations.
An online monitoring system for Fence line monitoring or peripheral monitoring.
Detection of PH3 at TLV level, for personal protection and safety.
Gas Detected: PH3
Detection Principle: Electrochemical Sensor
Range: 0-20 ppm
Resolution: 0.01 ppm
Communication / Interface: MODBUS
Quick connectors for quick, easy and error-free connection
Micro-controller-based system with pluggable smart sensor
Sensor / Transmitter
Gas Detected: PH3
Detection Principle: Electrochemical Technology
Detection Range: 0-20 PPM
Resolution: 0.01 PPM***
Gas Sampling: Diffusion Type
Warm up Time: Less than 2 min.
Response Time (T90): Less than 60 sec
Accuracy: +/- 2% *
Drift: Less than 2%
Power Supply: 24V DC (Provided from Master Controller)
Communication / Interface: MODBUS
Operating Temperature: 0 – 50 °C
Operating Life of Sensor: 2 years **
Dimension: 210 x 150 x 90 mm (L x W x H)
Construction Material: Polyester
Electrical Connections: Quick Connectors with Polarity; for quick, easy and error-free connection
