FQTA-TKN-6100

Uniphos Online Ammoniacal Nitrogen Analyzer

Enquire Now

The presence of Nitrogen in the form of Ammonium/ Ammonia is termed as Ammoniacal Nitrogen in the influent/ sample

The Uniphos online Ammoniacal Nitrogen analyzer is an accurate, stable and fully automatic analyzer designed to measure Ammoniacal Nitrogen of process / surface water samples using an electrochemical sensor. No human intervention is required during the measurement as the analyzer is completely automated.
The inbuilt diagnostics feature provides an alarm if there are any faulty components or if the reagent falls below the minimum level. Equipped with a next generation touchscreen HMI for display and programming, the analyzer provides a variety of data communication options such as RS-485 MODBUS and industry standard 4-20 mA analog output

Application

  • Municipal Water
  • Industrial influent/Effluent
  • Field / laboratory
  • Process and Surface water

Features

  • Simple in operation
  • No sample pre treatment
  • Only two Reagents with very less consumption per analysis
  • A fully automated system with a industry accredited Program Logic controller (PLC) and Human Machine Interface (HMI)
  • Built in diagnostic features for reagent level alarm and the component malfunctions
  • Data communication compatible with required SPCB/CPCB norms

Specifications

  • Measurement Technique: Electrochemical Sensing
  • Measuring Range: 10 – 500 ppm
  • Measurement Accuracy: ±10 ppm for 10-100 ppm
                                               ±10% of reading for ≥100 – 500 ppm
  • Calibration: Single point calibration
  • Sample injection: Automatic
  • Sampling interval: User Programmable
  • Analysis time: 15 min
  • Display: TFT LCD touch panel
  • Reagents: NaOH, H2SO4, distilled water.
  • Power: 230 V AC/ 60 Hz
  • Data Communication: RS-485 & 4-20 mA
  • Instrument dimensions: H=1200mm, L=400mm, B=600mm
  • Instrument weight: 65 kgs
